Impact Sockets & Accessories

zoom

1/4"DR.

Standard Length US Type

Standard Length - Metric & SAE (AF)



Code Part No. Size (mm) D1 (mm) D2 (mm) T (min. mm) L (mm)
26120402 US62M4 4 7.6 13 5 23
26120452 US62M45 4.5 8.2 13 5 23
26120502 US62M5 5 8.8 13 5 23
26120552 US62M55 5.5 9.5 13 5 23
26120602 US62M6 6 10 13 7 23
26120702 US62M7 7 11.3 13 7 23
26120802 US62M8 8 12.5 13 7 23
26120902 US62M9 9 14 14 7 23
26121002 US62M10 10 15 15 7 23
26121102 US62M11 11 17 17 8 23
26121202 US62M12 12 18 18 8 23
26121302 US62M13 13 19 19 8 23
26121402 US62M14 14 20 20 8 23
26121502 US62M15 15 21 21 8 23



Code Part No. Size (Inch) D1 (mm) D2 (mm) T (min. mm) L (mm)
26220062 US62H316 3/16" 8.5 13 5 23
26220072 US62H732 7/32" 9.5 13 5 23
26220082 US62H14 1/4" 10.3 13 5 23
26220092 US62H932 9/32" 11.3 13 7 23
26220102 US62H516 5/16" 12.5 13 7 23
26220112 US62H1132 11/32" 14 14 7 23
26220122 US62H38 3/8" 14 14 8 23
26220142 US62H716 7/16" 17 17 8 23
26220162 US62H12 1/2" 19 19 8 23
26220182 US62H916 9/16" 20 20 8 23
